Determining the location of Test point EDL download mode Xiaomi Redmi 6a - One type of android smartphone output from Xiaomi is Xiaomi Redmi 6a which has quite good features and specifications.

Quite a lot of users choose Xiaomi Redmi 6a ni android phone type to be used as a personal phone to support activities in work, entertainment, internet and also playing games.

Short specifications of Xiaomi Redmi 6a phone:

  • IPS LCD screen 5.45 inches, Screen resolution: 720 x 1140 pixels.
  • Mediatek Helio A22 Chipset, Quad-core CPU 2.0 GHz Cortex-A53.
  • Internal memory is 16 GB/32 GB, microSD up 256 GB using dual Sim Card.
  • RAM size 2 GB/3 GB.
  • 13MP LED flash rear camera, 5 MP front camera.
  • Non-removable Battery Capacity of 3000 mAh.

The advantages of the Xiaomi Redmi 6a Android smartphone:

The performance of the phone is quite resilient, capable of producing powerful graphics. The capacity of non-removable batteries used is also considerable. For the price offered is quite affordable compared to the type of phone with different brands.

Disadvantages of Xiaomi Redmi 6a smartphone:

Not accompanied by the fingerprint sensor

After knowing the specifications, advantages, and also less than Xiaomi Redmi 6a phone, then next we will discuss how to determine the location of pinout test point EDL mode on Xiaomi Redmi 6a smartphone.

With the test point then we can flash or reinstall on Xiaomi Redmi 6a smartphone. This is done if the Xiaomi phone has not been done unlock the bootloader.



Some advantages if doing a test point EDL download mode Xiaomi Redmi 6a Android smartphone:

  1. To reinstall your phone
  2. Overcoming boot loop phones
  3. Xiaomi phones can't get into the Fastboot menu
  4. Fix Xiaomi phones that are hard brick or completely off

To determine where the pinout test point is on the Xiaomi Redmi 6a smartphone, you need to dismantle the phone as a whole to see where the test point is located on the mainboard of the phone.

Location pinout test point EDL download mode Xiaomi Redmi 6a

In the diagram image below is seen the PCB board or mainboard of the Xiaomi Redmi 6a phone. You can do the test point by connecting the two pinout points by using the help of tweezers or jumper cable while connecting your phone to your PC or laptop with a data cable.
 Pinout Test Point EDL Download Mode Xiaomi Redmi 6A

If the test point method is successful, it will be visible on the screen of the PC or laptop of the Qualcomm driver installation process.

After the successful installation of Qualcomm drivers, you can already reinstall or flashing by using the Mi Flash tools app by also equipped with stock ROM files for Xiaomi Redmi 6a android phones that you want.

Such information and also a short tutorial to determine the position of test point EDL download mode Xiaomi Redmi 6a. I hope this information can be useful for all of you who are looking for a way to reinstall with the test point method.
